Number of Doors Controlled 2 Doors
Number of Readers Supported 4
Types of Readers Supported 26-bit Wiegand
Number of Inputs 6 (2 Exit Devices, 2 Door Contacts and 2 Aux)
Number of Outputs 4 (2 Form C relay for lock and 2 Form C relay for Aux output)
Card holders Capacity 30000
Log Events Capacity 100000
Communication RS485, TCP/IP
Recommended Power Supply 1.5A, 12V DC
Mounting Wall Mount
Enclosure Powder Coated Aluminium
Dimensions (Board Only)
160*106mm (6.3*4.17in)
Dimensions (Bundle Only)
380*80*280mm (15*3.15*11in (l*w*h)
