ARD512-W2(868)

Port

Alarm Input

2 (NO/NC)

Microphone

Highly-sensitive omnidirectional microphone

Function

Button

1 × power button

Remote Update

Cloud update

Low Battery Detection

Yes

Tamper

Yes

Technical

Detection Range

Max. 9 m (29.53 ft)

Specifications of Glass to be Detected

Glass type: Tempered, double-glazed, laminated, wired, plate and float
Glass thickness: 2.4 mm–6.4 mm (0.09″”–0.25″”)
Glass size: 0.3 m × 0.3 m to 3 m × 3 m (0.98 ft × 0.98 ft to 9.84 ft × 9.84 ft)

Test Mode

Yes

LED Indicator

1 × green alarm indicator

Scenario

Indoor

Operating Current

45 uA

Alarm Current

50 mA

Wireless

Carrier Frequency

868.0 MHz–868.6 MHz

Transmitter Power (EIRP)

Limit 25 mW

Communication Mechanism

Two-way

Communication Distance

1,600 m (5,249.34 ft)

Encryption Mode

AES128

Frequency Hopping

Yes

General

Power Supply

1 × CR123A battery

Battery Model

CR123A

Battery Life

3 years (The external input type is NO)
1 year (Both external sensors are enabled, and the input type is NC)

Power Consumption

Max. 150 mW
